P. 2
TREAT/NO DISCHARGE MODE; FIG 2 SWITCH PANEL
OPERATION
Press no discharge button on panel once to toggle
mode from treat to no discharge. Manual Start/Stop
If position sensing shutoff valve is installed Disabled for no discharge mode
close valve to set no discharge mode
Open Valve and press treat/no discharge button on Press to switch between
panel to set treat mode. Treat and No Discharge
If key switch panel is installed, turn key switch to mode
no discharge to set no discharge mode. Error/No discharge LED:
Turn key to treat position and press treat /no discarge Flashing (every 1/4 sec):
button on panel to set treat mode. Check tablet cartridge
Note: Pause at least 10 seonds after mode is switched Solid:
to switch again. Check motor fuse
Basic Operation: Flashing(every 4 sec):
When the Hold n’ Treat System is in treatment No discharge mode
mode and level in holding tank is above the LOW
LEVEL, treatment cycle starts. Macerator pump Empty:
is activated and moves approximately 1 gallon of Treatment LED: Activates Drain
waste from the holding tank to the treatment tank. Flashing(1/4 sec): Manifold and Air
Treatment cycles runs for 2 minutes.At the end of the Treatment cycle Fill: Pump momentarily
cycle , system waits in treatment mode for 8 seconds Flashing (3 sec): Activates Water Valve and
and cycle is repeated until the level in the tank falls Treat mode
below the LOW LEVEL. If the LOW LEVEL is Both LED flashing: fills Tablet Dispenser
momentarily
not reached after ten cycles, the system will enter Tank full level
into a COOL DOWN mode for ten minutes. When FIG 3
the system is set to NO DISCHARGE, waste will TABLET DISPENSER
enter the holding tank and will not be treated until
set to treatment mode. Overfill
PROCESSING LED: Sensor
• blinks twice per second when unit is in treatment
cycle.
• blinks every 3 second if unit is in treat mode and
holding tank level is below LOW level or in be-
tween treatment cycle
• blinks twice per seconds with error LED when
holding tank level is above HIGH level.
No discharge LED:
• blinks every 4 seconds when in no discharge mode
• blinks twice per seconds when tablet dispenser Low Tablet
needs to checked for tablets or water level. Sensor
• on solid when motor fuse is blown
START/STOP BUTTON: Press start button to start Water Line
a cycle during treat mode to process holding tank
below LOW level. DO NOT RUN MACERATOR Tablet Holder
PUMP DRY.
Note: There is 8 seconds pause between cycles.
