Page 11 - Raritan Hold-N-Treat for Purasan EX L519v0919
P. 11
INITIAL SETTING OF “FILL” and “EMPTY” After hold time, air pump and drain valve will drain
Must be completed during installation to be sure water solution. Make sure that water is drained from entire
reaches level mark on dispenser. tube up to treatment tank. Increase empty time using
1. All settings should be done with water source (on step 6 if drain time is not sufficient. After drain cycle,
board pressure pump or shore water supply) that will air pump and water solenoid will stay on for 10 more
be used with PURASAN. Settings done will only seconds (non-programmable). This will flush the check
be valid for that source, and may need to be repro- valve near the tank. Repeat flush cycle to check fill time.
grammed if another source is utilized. Lid must be If water level is not filling up between lines, increase or
closed tight during setting and use. decrease fill time using steps 2 thru 6.
2. Dispenser must not contain tablets during initial NOTE: The cycle after the drain cycle can be stopped PROGRAMMING
set-up. Program “fill” time without tablet to reach by pressing start/stop button at any time.
1/4” below top marked lines, Unplug sensor cable at With Tablets: Follow start up procedure. Load tablets
Control Module. and plug sensor cable. Press “START/STOP” button.
3. With power on, press “fill “and count seconds un- The water should fill up between level line. Make final
til water reaches to water level mark on dispenser. adjustment as per above instructions if needed.
Record seconds as fill. If recorded seconds are greater Setting of Transfer/macerator pump on time:
than 18 , Open the hole to approx 1/8” in metering NOTE: Pump time is set to 10 seconds as shipped.
washer between water valve (221352) and check valve • Hold the EMPTY & FILL buttons down together for
(PX50W) and repeat. three seconds. The error LED will give three quick
4. Empty water below tablet dispenser bottom and entire flashes indicating you have entered program mode -
3/8” tube till treatment tank while pressing “empty” release both buttons.
button and counting seconds. Record seconds as • Press No Discharge button (FIG 11, next to start/stop
empty button) as many times as needed to set pump time
5. SET PRELIMINARY “FILL” time: (One push = 1 sec’s, two= 2 sec’s, three= 3 sec’s
• Hold the EMPTY & FILL buttons down together for etc.). The LED will flash once indicating a valid key
three seconds. The error LED will give three quick push.
flashes indicating you have entered program mode - NOTE: Maximum is 20 seconds.
release both buttons. • Push the START/STOP button to store this value
• Press “FILL “ button as many times as fill seconds (the unit will flash three times indicating the time has
recorded in step 2. example: 8 seconds press 8 times. been set and you have left program mode).
Note: maximum is 20 and minimum is 2.
• Push the “START/STOP” button to store this value NOTE: When the waste/water level in the tank is high
(the unit will flash three times indicating the time has enough to activate the treatment cycle and it is in a treat-
been set and you have left program mode). ment cycle, the time settings for FILL, EMPTY and/or
6. SET PRELIMINARY “EMPTY” time: Transfer/ Macerator Pump can be adjusted by:
• Hold the EMPTY & FILL buttons down together for • Press START/STOP button
three seconds. The error LED will give three quick • Within 8 seconds of pressing the Start/Stop button,
flashes indicating you have entered program mode - proceed with reprogramming as instructed. After the
release both buttons. Start/Stop button is pressed, the treatment cycle
• Press “EMPTY “ button as many times as empty should begin after several seconds. If further
seconds recorded in step 4. adjustments are needed, repeat process.
Note: Minimum time is set at 10 seconds. Each press FIG 11
of the EMPTY button will add 1 second to minimum
time. Maximum is 20 seconds. Treatment Macerator
• Push the “START/STOP” button to store this value Pump
(the unit will flash three times indicating the time has
been set and you have left program mode).
7. TEST SETTINGS: ERROR
Without Tablets: Press start/stop button. Water should
fill up in the dispenser at least up to lower line but no
higher than half way between line. Hold time of water FILL EMPTY
is 20 seconds and not programmable.
L519 _0919jlc 11
